Taper Bushing Locking锥套尺寸数据表（单位mm）
| 型号 | 大端直径 | 小端直径 | 高度 |
| 1008 | 35.2 | 32.08 | 22.3 |
| 1108 | 38.38 | 35.26 | 22.3 |
| 1210 | 47.62 | 44.07 | 25.4 |
| 1215 | 47.62 | 42.29 | 38.1 |
| 1310 | 50.8 | 47.25 | 25.4 |
| 1610 | 57.15 | 53.6 | 25.4 |
| 1615 | 57.15 | 51.82 | 38.1 |
| 2012 | 69.85 | 65.4 | 31.8 |
| 2017 | 69.85 | 63.63 | 44.5 |
| 2517 | 85.73 | 79.51 | 44.5 |
| 2525 | 85.73 | 76.85 | 63.5 |
| 3020 | 107.96 | 100.86 | 50.8 |
| 3030 | 107.96 | 97.31 | 76.2 |
| 3535 | 127 | 114.56 | 89 |
| 3525 | 127 | 118.12 | 63.5 |
| 4040 | 146.05 | 131.85 | 101.6 |
| 4030 | 146.05 | 135.4 | 76.2 |
| 4545 | 161.93 | 145.95 | 114.3 |
| 4535 | 161.93 | 149.49 | 89 |
| 5040 | 177.8 | 163.6 | 101.6 |
| 5050 | 177.8 | 160.05 | 127 |
| 锥套型号 | 轴孔可选直径（电机轴直径） |
| TB锥套1008 | 10,11,12,14,16,18,19,20,22,24,25 |
| TB锥套1108 | 10,11,12,14,16,18,19,20,22,24,25,28 |
| TB锥套1210 | 11.12.14.15.16.18.19.20.22.24.25.28.30.32 |
| TB锥套1215 | 11.12.14.15.16.18.19.20.22.24.25.28.30.32 |
| TB锥套1310 | 14.15.16.18.19.20.22.24.25.28.30.32.35 |
| TB锥套1610 | 14,15,16,18,19,20,22,24,25,28,30,32,35,38,40,42 |
| TB锥套1615 | 14.15.16.18.19.20.22.24.25.28.30.32.35.38.40.42 |
| TB锥套2012 | 18.19.20.22.24.25.28.30.32.35.38.40.42.45.48.50 |
| TB锥套2017 | 18.19.20.22.24.25.28.30.32.35.38.40.42.45.48.50 |
| TB锥套2517 | 20.22.24.25.28.30.32.35.38.40.42.45.48.50.55.60.65 |
| TB锥套2525 | 20.22.24.25.28.30.32.35.38.40.42.45.48.50.55.60 |
| TB锥套3020 | 25.28.30.32.35.38.40.42.45.48.50.55.60.65.70.75.80 |
| TB锥套3030 | 25,28,30,32,35,38,40,42,45,48,50,55,60,65,70,75.80 |
| TB锥套3525 | 35.38.40.42.45.48.50.55.60.65.70.75.80.85.90 |
| TB锥套3535 | 35.38.40.42.45.48.50.55.60.65.70.75.80.85.90.95 |
| TB锥套4030 | 40.42.45.50.60.65.70.75.80.85.90.95.100 |
| TB锥套4040 | 40.42.45.50.60.65.70.75.80.85.90.95.100 |
| TB锥套4535 | 55.60.65.70.75.80.85.90.95.100.105.110 |
| TB锥套4545 | 55.60.65.70.75.80.85.90.95.100.105.110 |
| TB锥套5040 | 60.65.70.75.80.85.90.95.100.105.110.115.120.125 |
| TB锥套5050 | 60.65.70.75.80.85.90.95.100.105.110.115.120.125.130 |
