XLD梅花形星型弹性联轴器GS减震、缓冲圈配件尺寸表
| TYPE | OD | ID | THICKNESS1 | THICKNESS2 | Quantity of petal |
| 型号 | 外径 | 内径 | 厚度1 | 厚度2 | 瓣数 |
| GS-05 | 10 | — | 6 | 4 | 4 |
| GS-07 | 14 | — | 8 | 8 | 4 |
| GS-09 | 20 | 7 | 10 | 8 | 4 |
| GS-12 | 25 | 8 | 12 | 10 | 4 |
| GS-14 | 30 | 10 | 12 | 10 | 4 |
| GS-19 | 40 | 18 | 14.5 | 12 | 6 |
| GS-24 | 54 | 26 | 15.2 | 14 | 8 |
| GS-28 | 65 | 30 | 19 | 15 | 8 |
| GS-38 | 80 | 38 | 22 | 18 | 8 |
| GS-42 | 95 | 46 | 24 | 20 | 8 |
| GS-48 | 104 | 51 | 25.5 | 20.5 | 8 |
| GS-55 | 120 | 60 | 27 | 22 | 8 |
| GR-65 | 135 | 68 | 32 | 26 | 8 |
| GR-75 | 160 | 80 | 37 | 30 | 10 |
